NEC Article 590 and all of its subsets are in relation to Temporary Installations. This means that it involves the electrical protection provisions for all temporary electrical power and lighting installations. We are going to take a closer look at subset 590.6 (and more specifically 590.6(A)), as it relates to the GFCI for temporary powered products. This subset, and all of its extensions, include:

590.6: This section is the specific destination for Ground-Fault Protection for the personnel for all temporary wiring installations in a plethora of different working environments (from demolition, construction, remodeling, repair, and maintenance, etc.). The article also states that it needs to comply with requirements set in 590.6(A) & (B). Next we will look at section 590.6(A) to see some of the listed requirements for this section of the code

590.6(A): this section states (specifically for receptacle outlets) for the temporary use power to equipment in the listed locations (from section 590.6) need to comply with the requirements of 590.6(A)(1) through 590.6(A)(3). These sections state, in order:

1.) This part is for the receptacle outlets that are not part of the permanent venue wiring. This including 125VAC, single-phase, up to 30-Amp configured receptacles that are not a part of the fixed wiring of the building /structure, and which are in use by personnel must encompass ground-fault circuit-interrupter (GFCI) protection. On top of this, any required GFCI protection for personnel, listed cord sets/devices incorporating listed GFCI protection must be of the portable construction type.

2.) This section is for the existing receptacles that are a part of the permanent infrastructure. They will require GFCI protection for personnel for all 125VAC, single-phase, up to 30-Amp receptacle outlets. Just as the previous section, this is accomplished with the use of “portable type listed cord sets/devices.

3.) The last extension of subset 590.6(A) is concerning receptacles integral to a 15kW or smaller portable generator. Panel integrated 125VAC and 125/250VAC, single-phase, up to 30-Amp receptacle outlets shall provide listed ground-fault circuit-interrupter (GFCI) protection for personnel. This section also goes on to dictate that “if used in a wet/damp location, follow the guidelines from Article 406(A) & (B) (which dictates that they be weather resistant listed, and incorporate hinged doors for increased ingress protection).

Section 590(B) gives fairly the same information, except it is the rules & regulations for “other” (as in other than the listed locations from 590.6(A)) receptacle outlets. All and all, this Article of the NEC code dictates the standards for electrical protection of temporary power supply operations, which also tie in similarly with OSHA standards in this instance.

1. [15 Amp Inline GFCI](/gfci/15-amp-inline-gfci)
2. [15 Amp Plug GFCI](/gfci/15-amp-plug-gfci)
3. [20 Amp Portable GFCI](/gfci/20-amp-portable-gfci)
4. [30 Amp Permanent GFCI](/gfci/30-amp-permanent-gfci)
5. [30 Amp Portable GFCI](/gfci/30-amp-portable-gfci)
6. [60 Amp 3-phase GFCI](/gfci/60-amp-3-phase-gfci)
7. [60 Amp SPGFCI](/gfci/60-amp-spgfci)


NEC Code Application 590.6


NEC Article 680 and all of its subsets involve swimming pools, fountains, and similar installations. In particular, that means that this Article deals with the electrical protection of all equipment involved in swimming, wading, therapeutic, & decorative pools, fountains, hot tubs, spas, and hydromassage bathtubs. As in many other NEC Articles, there is mention of GFCI protection, but unlike many other of the Articles there are many parts that involve specifications/needs of GFCI protection in this section (8 to be exact). Therefore, we will go over the 8 different subsets individually, which are:

680.5: This section dictates the overarching reach of Ground-Fault Circuit-Interrupter (GFCI) and Special Purpose Ground-Fault Circuit-Interrupter (SPGFCI) protection. There are 3 parts to this subset, and they are as follows:

A.) This part, which is listed as general, just dictates that all GFCI and SPGFCI requirements in this article must follow 210.8 (Class A protection) unless otherwise directed in the next 2 parts.

B.) This section is specified for the equipment that is not more than 150V to ground. In more detail, that is branch circuits not exceeding 150VAC to ground, 60A, and that are single or three phase, need Class A GFCI protection.

C.) This part deals with equipment in excess of 150V to ground. In more detail, it’s for receptacles & outlet junctions on branch circuits operating at voltages greater than 150V to ground, although not exceeding a 480V maximum system voltage, shall be equipped with SPGFCI protection with a maximum trip setting of 20mA.

680.21: This subset of Article 680 deals with motors involved in pools. There are 2 parts in this subsection that have relation to GFCI & SPGFCI protection which includes:

C.) This article is for the ground fault protection of outlet junctions for pool motors. It states that said motors need to have GFCI protection that comply with either 680.5(B) or (C) (based on voltage specifications).

D.) This part handles pool pump motor replacement or repair. If a motor is replaced/repaired, the installation must be provided with the proper GFCI or SPGFCI protection according to 680.5(B) or (C).

680.22: This subsection deals with the lighting, receptacles, and equipment for permanently installed pools. further down in this section, part 680.22(B)(4), its states that there needs to be GFCI or SPGFCI protection in accordance with 680.5(B) or (C) for all “luminaries, lighting outlets, and ceiling-suspended (paddle fans)” that are between 5-10ft (1.5-3m) from the inside of a pools walls.

680.32: This section was made to give specification for GFCI and SPGFCI protection guidelines for all of the electrical equipment (x. power-supply cords), used with storable pools/hot tubs/spas. Where they shall have the protection in accordance with either 680.5(B) or (C) depending on voltage specification of the equipment. It states that any receptacles of 125V through 250V, up to 60 Amps, situated within 20ft (6m) of the containment walls of the specific storable pool/hot tub/spa also needs the listed protection above.

680.43: This subsection states the specifications for the indoor installations of hot tubs & spas. The ground fault protection part of this subsection, 680.43(A)(2), states that any receptacles of 125V through 250V, up to 60 Amps, situated within 10ft (3m) of the containment wall of the hot tub/spa requires GFCI protection according to 680.5(B) or SPGFCI protection according to 680.5(C), depending on the electrical specifications of the hot tub/spa.

680.44: This section continues with giving GFCI and SPGFCI protection guidelines for hot tubs & spas. There are 3 sections which include:

A.) This is the “general” section, stating that unless otherwise stated in the next two parts, the spa/hot tub needs to follow section 680.5(B) or (C) for required GFCI or SPGFCI protection according to power specifications if the appliance.

B.) Any of the Listed subcomponents (lights, blowers , pumps, heaters, sanitizers , etc.) involved with a spa/hot tub that is a Listed product (encompassing an integral GFCI in its construction) does not need additional ground fault protection.

C.) this part of subset 680.44 has the guidelines for gas-fired water heaters. It says that any circuit serving a gas-fired hot tub/spa heater operating above the intrinsic safety voltage limit, requires ground fault protection.

680.58: This subsection dictates the GFCI and SPGFCI protection for fountains. It states that all receptacles of 125V through 250V, up to 60 Amps, situated within 20ft (6m) of a fountain basin shall have GFCI protection correlating with 680.5(B) or SPGFCI protection according to 680.5(C).

680.59: This subsection dictates the GFCI and SPGFCI protection for non-submersible pump motors. It states that the junction outlets that supply all permanently installed non-submersible pump motors are required to have GFCI protection according to 680.5(B) or SPGFCI protection according to 680.5(C) when applicable.

There are a lot of different parts to this Article of the NEC code regarding to GFCI and SPGFCI protection, but the bottom line is you are either following code 210.8 for Class A protection, and if there is any question or additional information added follow 680.5(B) for GFCI protection and 680(C) for SPGFCI protection.
